DJI Enterprise · Matrice 4 Series
DJI Matrice 4T, 4TD, 4E and 4D: the Matrice 4 series compared
The DJI Matrice 4T is the compact thermal imaging drone for wildlife rescue, species conservation, and emergency services; the DJI Matrice 4TD is the weatherproof version for Dock 3. The DJI Matrice 4E and DJI Matrice 4D do not have thermal imaging: the 4E is the surveying drone, and the 4D is the version for Dock 3. Here you can see how the four differ and which one is right for your needs.
Innovations
What makes the Matrice 4 series special
An overview of the most important innovations of the Matrice 4 series.
-
Measure
Laser rangefinder
Measures distances up to 1,800 m.
-
position
RTK on board
Hovering with RTK accurate to ±0.1 m.
-
camera
Color telephoto camera with high light sensitivity
Telephoto lens with 168 mm, 1/1.5-inch sensor and 48 megapixels.
-
steering
New remote control
The DJI RC Plus 2 Enterprise controls all models in the series.
-
Thermal image
Thermal imaging with a narrower field of view
53 mm focal length and 45° field of view for 4T and 4TD.
-
AI
Onboard AI
The free AI model marks fawns and clutches in the live image (Beta, 4T and 4TD).
-
POICloud
New possibilities for POICloud integration
Plans and locations are transferred between the drone and POICloud via POIConnect.
-
accuracy
Higher accuracy when measuring objects
Laser rangefinders and RTK help to measure objects more accurately.
-
software
New software features
3D area measurement with the laser rangefinder, cruise control for smooth flying, a high-resolution thermal imaging mode for search and rescue operations, even in winter and rain (4T and 4TD), and new flight routes such as the patrol route.
The models
Matrice 4T, 4TD, 4E and 4D at a glance
-
Recommended
DJI Matrice 4T
The compact thermal imaging drone for mobile use: thermal imaging with 640 × 512 pixels (1280 × 1024 with super-resolution), three additional cameras, laser rangefinder up to 1,800 m and up to 49 minutes of flight time per battery. It works with all POICloud programs and with the onboard AI and can be expanded with a spotlight, speaker and cellular dongle.
DJI Matrice 4T in the shop -
For all weather conditions
DJI Matrice 4TD
It features the same cameras and thermal imaging as the Matrice 4T, plus IP55 protection, operation from -20 to 50 °C, and anti-icing propellers. It flies for up to 54 minutes but, at 1,850 g, weighs more than the 4T. You can control it from Dock 3 or manually with the DJI RC Plus 2 Enterprise.
DJI Matrice 4TD in the shop -
For surveying
DJI Matrice 4E
The surveying drone without thermal imaging: wide-angle camera with a 4/3-inch sensor, 20 megapixels, mechanical shutter and RAW format (DNG), plus medium telephoto and telephoto lenses, each with 48 megapixels, and a laser rangefinder. Designed for surveying, mapping, construction, and mining.
Request DJI Matrice 4E -
For the Dock 3
DJI Matrice 4D
The same cameras as the Matrice 4E, but built for the Dock 3: IP55 protection rating, operation from -20 to 50 °C, anti-icing propellers, and up to 54 minutes of flight time. It doesn't have thermal imaging; that's offered by the Matrice 4TD. You can also fly it manually with the DJI RC Plus 2 Enterprise.
Request DJI Matrice 4D
Comparison
DJI Matrice 4T, 4TD, 4E or 4D: the differences
| feature | Matrice 4T | Matrice 4TD | Matrice 4E | Matrice 4D |
|---|---|---|---|---|
| Thermal image | 640 × 512 pixels, 1280 × 1024 with super-resolution | 640 × 512 pixels, 1280 × 1024 with super-resolution | no thermal image | no thermal image |
| Wide-angle camera | 48 MP, 1/1.3 inch | 48 MP, 1/1.3 inch | 20 MP, 4/3 inch, mechanical shutter | 20 MP, 4/3 inch, mechanical shutter |
| Medium-telephone and telephoto | 70 mm and 168 mm, each 48 MP | 70 mm and 168 mm, each 48 MP | 70 mm and 168 mm, each 48 MP | 70 mm and 168 mm, each 48 MP |
| Laser rangefinder | up to 1,800 m | up to 1,800 m | up to 1,800 m | up to 1,800 m |
| Weight | 1,219 g | 1,850 g | 1,219 g | 1,850 g |
| Flight time per battery | up to 49 minutes | up to 54 minutes | up to 49 minutes | up to 54 minutes |
| Wind resistance | 12 m/s during takeoff and landing | 12 m/s during operation as well as during takeoff and landing | 12 m/s during takeoff and landing | 12 m/s during operation as well as during takeoff and landing |
| Operating temperature | -10 to 40 °C | -20 to 50 °C | -10 to 40 °C | -20 to 50 °C |
| Protection class and weather | DJI provides no information | IP55, anti-icing propeller | DJI provides no information | IP55, anti-icing propeller |
| dock | no | Dock 3 or manually with RC Plus 2 Enterprise | no | Dock 3 or manually with RC Plus 2 Enterprise |
| Typical use | Fawn rescue, species protection, emergency services | Operation in all weather conditions, dock operation | Surveying and mapping | Aerial photography in all weather conditions, dock operation |
Areas of application
The perfect Matrice 4 for your needs
-
Fawn rescue
Locate fawns using thermal imaging before mowing and relay their locations to ground crews in real time. For mobile operations on changing meadows, we recommend the Matrice 4T or 4TD.
Fawn rescue using a drone -
Breeding bird and species protection
Locate the nests of meadow-nesting birds with minimal disturbance, measure their positions, and locate them again on the ground with the team.
Bird breeding protection using drones -
Fire brigade and disaster relief
Search for missing persons, locate hotspots, and provide live video feeds to the command center and control center.
Drones for fire departments and emergency services -
Photovoltaics and inspection
Find hotspots, defective bypass diodes and contamination in the thermal image, each finding with coordinates.
PV inspection with a thermal imaging drone -
forestry
Detect damage in the stock early, mark conspicuous trees and navigate to them using the POIApp.
Drones in forestry -
Surveying and mapping
Create orthophotos, surface models, and point clouds and transfer them to GIS or CAD. The Matrice 4E, with its 4/3-inch wide-angle camera, is designed for this purpose; the 4D has the same camera.
Surveying with a drone
Sets
Matrice 4T and 4TD as a complete set
Our DJI Matrice 4T and DJI Matrice 4TD packages are available in Basic, Standard, and Professional versions. Current prices are available in our online shop. POIConnect and POIStudio are included free of charge with every drone purchase, and you'll also receive instruction, online training, and premium support.
For the DJI Matrice 4E, DJI Matrice 4D, multiple drones, or special equipment, we'll create a customized offer for you.
software
POICloud and onboard AI with the Matrice 4
Die Matrice 4T und die Matrice 4TD verbinden sich über POIConnect mit der POICloud. Ihr plant Flächen und Aufträge, schickt Flugpläne auf die Fernsteuerung und teilt Fundorte und das Livebild der Drohne mit den Helfern am Boden. Welche Drohne mit welchem Programm arbeitet, steht unter Welche Drohne passt zur POICloud?.
Für die Matrice 4 gibt es unser kostenloses KI-Modell. Es läuft direkt auf der Drohne und markiert Rehkitze und Gelege im Livebild. Die KI ist noch im Beta-Stadium, ob es ein Kitz ist, entscheidet immer der Mensch.
Frequently Asked Questions
Frequently Asked Questions about the DJI Matrice 4 Series
Is there a DJI Mavic 4T?
No. There is no Mavic 4T. People searching for that usually mean the DJI Matrice 4T, the successor to the DJI Mavic 3T. Like the Mavic 3T, it has thermal imaging, but it's a drone in the Matrice series.
Matrice 4T or 4TD: which one is right for me?
The Matrice 4T is sufficient for most mobile applications. Choose the Matrice 4TD if you want to fly in all weather conditions or operate the drone from Dock 3.
What is the difference between the Matrice 4E and the Matrice 4T?
The Matrice 4E does not have thermal imaging. Instead, it features a wide-angle camera with a 4/3-inch sensor, 20 megapixels, and a mechanical shutter, designed for surveying and mapping. For thermal imaging searches, use the Matrice 4T or 4TD.
What is the DJI Matrice 4D?
The Matrice 4D is the variant for the Dock 3 without thermal imaging. It has the same cameras as the Matrice 4E and the same design as the Matrice 4TD: IP55 protection rating, anti-icing propellers, and a flight time of up to 54 minutes. With thermal imaging, this design is available as the Matrice 4TD.
Can I fly the Matrice 4TD without a dock?
Yes. The 4TD can also be flown manually with the DJI RC Plus 2 Enterprise; it's not docked. The same applies to the Matrice 4D.
What IP rating does the Matrice 4TD have?
The Matrice 4TD and Matrice 4D have an IP55 rating and anti-icing propellers. They operate in temperatures ranging from -20 to 50 °C. DJI does not specify an IP rating for the Matrice 4T and 4E; their operating range is -10 to 40 °C.
Which thermal imaging drone is suitable for fawn rescue?
We recommend the DJI Matrice 4T. It's compact and features a thermal image with 640 × 512 pixels and a laser rangefinder. For those who want to fly in all weather conditions, the Matrice 4TD is the right choice. Learn more at Rescuing fawns with a drone.
How much does the Matrice 4T cost?
That depends on the equipment. The sets are available as Basic, Standard and Professional; current prices can be found in the online shop.
